Model | GBP 220100 | GBP 220200 | GBP 384100 | GBP 384200 | GBP 384500 | GBP 3841000 |
Type of core | Lithium iron phosphate |
Rated energy(KWH) | 22 | 44 | 40 | 80 | 200 | 400 |
Nominal capacity (AH) | 100 | 200 | 100 | 200 | 500 | 1000 |
Nominal voltage(VDC) | 220.8 | 384 | 384 |
Operating voltage range(VDC) | 179~259 | 312~450 | 312~450 |
Recommended Charge Voltage(VDC) | 242 | 420 | 420 |
Recommended discharge cutoff voltage(VDC) | 210 | 366 | 366 |
Standard charging current (A) | 50 | 100 | 50 | 100 | 250 | 500 |
Maximum continuous charge current(A) | 100 | 200 | 100 | 200 | 500 | 1000 |
Standard discharge current (A) | 50 | 100 | 50 | 100 | 250 | 500 |
Maximum continuous discharge current(A) | 100 | 200 | 100 | 200 | 500 | 1000 |
Working temperature | -20~65℃ |
Protection level | IP20 |
Communication interface | RS485/CAN two choose one |
Reference Weight (Kg) | 300 | 600 | 470 | 940 | 500 | 1000 |
Reference size(D*W*Hmm) | 530*650*1180 | 625*550*1810 | 530*550*1810 | (625*550*2040)*2 | 530*550*2020*5 | (625*550*1600)*10 |
