48v 10AH E-Bike Battery

Name:	48v 10AH E-Bike Battery
Type:	Lithium Battery
Battery type:	Rechargeable
Cycle life:	800-1000 Times
Charge voltage:	54.6±0.05 V
Discharge end voltage:	38 ±0.05 V
Charge current:	3A
Max Constant discharge current:	15A
Weight:	3kg, ≤ 3.5kg
Application:	Power Tools, Golf Carts, electric vehicles, Electric Wheelchairs, e-bike
Inquiry

ITEM	SPECIFICATION
Normal capacity	10Ah
Minimum capacity	10Ah
Normal voltage	48V
Charge voltage	54.6 ±0.05 V
Discharge end voltage	36.5±0.05 V
Standard charge current	3A
Standard discharge current	15A
Max charge current	0.5C(T>10℃)
Max charge current	0.2C(0℃-10℃)
Max continous discharge current	15A
Surface charge and discharge batteries maximum temperature	Charge:0℃-55℃;
	Discharge:-20℃-60℃
Working Temperature	Charge: 0°C ~ 45°C
Working Temperature	Discharge: -20°C ~ 55°C
Recommended Storage temperature	15°C ~ 35°C
Internal resistance	≤28mΩ(AC Impedance, 1000 Hz)
Cell dimension	Height : 390mm Thick:90
Weight	≤ 3.5kg
Cycle life	≥600cycle
	Under room temprature, the cell is charged to42.0V using 0.5C current and then store it for 10 min. Then it is discharged to 28V using 0.5C current. Recycle it continuously till the residual capacity is less than 80% of the rated capacity.
