Name:10KVA Power Supply Rack
Model:EKSS810H
Phase:Three Phase
Nominal DC Vol:360/384VDC
Output voltage:380/400Vac
Capacity:10KVA
Weight:180KG
Wave Form:Pure Sine Wave Online Ups
Transfer time:0 ms
Working principle:Double conversion
Warranty:3 Years
Type:On-line
Protection:Short Circuit/ overload/ over temperature/ over/under voltage
Application:Instrumentation/ industry/ security
Inquiry

Products Description

TypeEKSS20EKSS30EKSS40EKSS60EKSS80EKSS100EKSS120
Rated capacity(KVA)20KVA30KVA40KVA60KVA80KVA100KVA120KVA
Dimension(mm)450*660*1050500*860*1150720*900*1600
Weight210260360410520580630
Way of   workingOn-line power supply,   static bypass switch (no intermittent switching), double conversion   technology.
AC   INPUT
PhaseThree phase 380VAC (±20%)Three phase 380VAC (±20%)
Frequency50Hz/60Hz±5%
BATTERY
quantity30pcs 12V in series
Rated voltage360VDC
Floating   voltage405VDC
Charging   current5A1-30A(settable)
AC   output
Power factor0.8
phase3 phase+N+G
Rated voltage380VAC±3%(stable   load),380VAC±5%(fluctuated load)
Rated   frequency50Hz/60Hz±5%(grid   mode), 50Hz/60Hz±0.5%(battery mode)
Crest factor3:01
Wave formPure sine wave
Total   harmonic distortionLinear load<3%;non   linear load<5%
Voltage   transients<±5%(dynamic load)
Overload   capacity125% 1min,150% 1s
Inverter   efficiency85%
SYSTEM
Transfer time0ms
DisplayLCD+LED
Communication   interfaceRS232,SNMP( optional)
ProtectionOutput short-circuit,   output overload, over heat, system fault and so on
Environment
Protection   gradeIP20
Operating   environmentOperating ambient   temperature: 0 ~ 40 ℃;   relative humidity: 0% ~ 95% (non-condensing); <1000 meters (100 meters per   additional power down 1%, up to 5000 meters)
Cooling modeforced ventilation   (automatic speed control, temperature control)
Noise dB≤55dB
